Product Overview
The JM85 Dual Roller Brush Scrubber-Sweeper represents the high end of our walk-behind and compact ride-on scrubber range. Its dual roller brush configuration — rather than disc brushes — is specifically engineered for environments with mixed debris: the rolling brush action simultaneously dislodges, sweeps, and washes, while the integrated debris collection box captures solid litter and particles that disc scrubbers would simply push aside. ECO mode reduces energy draw during lower-intensity cleaning phases, extending the already-substantial 4–6 hour runtime on the quad 24V/200Ah battery pack. The front-wheel-drive layout improves manoeuvrability in tight spaces, while the adjustable seat accommodates operators of different heights for all-day comfort.
Technical Specification
| No. | Parameter | Value |
|---|---|---|
| 1 | Model | JM85 |
| 2 | Battery | 24V / 200Ah × 4 (Lithium Option Available) |
| 3 | Disc Motor Power | 500 W × 2 |
| 4 | Vacuum Motor Power | 550 W |
| 5 | Clean Water Tank | 110 L |
| 6 | Dirty Water Tank | 120 L |
| 7 | Cleaning Width | 650 mm |
| 8 | Squeegee Width | 1200 mm |
| 9 | Cleaning Efficiency | 6000 m²/h |
| 10 | Working Time | 4–6 Hours |
| 11 | Machine Weight | 360 kg |
| 12 | Dimensions (L×W×H) | 1600 × 1100 × 1400 mm |
| 13 | Drive System | Front-Wheel Drive |
| 14 | Operation Mode | ECO Energy-Saving Mode |
| 15 | Brush Type | Dual Roller Brush — Scrub + Sweep |
| 16 | Debris Box | Yes — Built-in Collection Box |
Key Features
- Dual Roller Brush — Scrub & Sweep Combined: Roller brush design simultaneously sweeps debris and scrubs the floor surface — one machine replaces both a sweeper and a scrubber in mixed debris environments.
- Built-in Debris Collection Box: Captures solid litter, paper, and coarse particles alongside liquid soiling — reducing post-cleaning manual sweep-up to virtually zero.
- ECO Energy-Saving Mode: Reduces motor power draw during lower-demand cleaning phases, extending runtime by up to 30% without compromising cleaning quality.
- Auto Brush Stop on Park: Brushes automatically stop when the machine is parked — protecting floor surfaces from disc marks and extending brush life.
- Auto Squeegee Lift on Reverse: Squeegee rises automatically when reversing, preventing blade damage and ensuring complete water recovery at turn points.
- Aluminium Alloy Solid Wheels (Polyester Tyre): Puncture-proof solid rubber tyres on aluminium alloy hubs eliminate flat tyre downtime entirely.
- Aviation Anti-Explosion Charging Port: Spark-free, sealed charging socket for safe battery charging in enclosed or low-ventilation commercial buildings.
- Adjustable Seat: Operator seat adjusts to accommodate different heights, reducing fatigue on extended cleaning shifts.
Application Scenarios
- Large logistics warehouses with mixed floor debris
- Manufacturing assembly line floors
- Airport cargo terminals and maintenance hangars
- Large supermarkets and grocery distribution centres
- Hospital service floors and loading docks
- University sports centres and indoor stadiums
JM85Specifications
